Voice 22
The Voice 22 is the culmination of exhaustive research, and for the first time, the MOON name has its own voice.
The Voice 22 is the culmination of exhaustive research, and for the first time, the MOON name has its own voice.
-
2-way loudspeakers.
-
The tweeter has a 29mm dome textile membrane and a large surround designed to work without a typical front plate, and is integrated into a custom waveguide, permitting a wider frequency range and lower crossover frequency.
-
The 155mm woofer has a cast-aluminum basket and mineral-filled polypropylene membrane that allows for a detailed midrange and strong, extended bass.
-
The crossover features a dual-layer PCB designed with carefully selected, high-quality metallized polypropylene film capacitors for optimal sound quality and long-term reliability.
-
The enclosure employs a unique technology called CGD (Curved Groove Damping) to control the panel resonances of the loudspeaker.
-
The Hover Base lends a visually striking appearance to the enclosure, which seems to gracefully float above the furniture. It ensures that the Voice 22 may be placed on virtually any surface without leaving a mark, while adding stability to the loudspeaker and guaranteeing sound integrity.
-
Tweeter29mm soft dome with waveguide
-
Woofer155mm mineral-filled polypropylene cone
-
Sensitivity89dB/2.83V/1m
-
Nominal Impedance6Ω
-
Recommended Power50W – 150W
-
Frequency Response (±3dB)55Hz – 24kHz
-
Frequency Range (-6dB)45Hz – 30kHz
-
Crossover Frequency1.5kHz
-
Dimensions (W x H x D)20cm x 35cm x 29cm
-
Weight10.5kg
