Shunyata Research

Typhon T30

Typhon T30

$10,875.00 CAD
$10,875.00 CAD
Description

The TYPHON T30 is the ultimate high-current, performance oriented power distributor in Shunyata Research’s lineup. The TYPHON T30 is a hot-rodded version of the acclaimed TYPHON T2 and is specifically designed to improve the performance of the world’s most powerful amplifiers. The T30 measurably reduces power line noise while dramatically enhancing amplifier power delivery and dynamic range.

 What differentiates the TYPHON T30 from the TYPHON T2 is its 30-amp capability. Shunyata Research collaborated with military connector manufacturer, Amphenol, to create 30-amp, twist lock connectors specifically for use in the TYPHON T30.  The quality and current carrying capacity of these connectors is unparalleled. Their performance nearly matches that of a hard-wired electrical connection, reducing the contact impedance that could otherwise affect peak-current transfer.
Specifications

Maximum Voltage:
90 – 125 VAC r.m.s. unregulated (US)
220 – 240 VAC r.m.s. unregulated (US)
220-240VAC r.m.s. unregulated (EU, AS)

Input Current Ratings:
US/AS maximum continuous current: 30A
EU maximum continuous current: 16A

Output Current Ratings:
US NEMA 2-20 Outlets: 20A
EU CEE7/3 Socket: 16A
Amphenol Outlet: 30A

Transient Suppression
Maximum transient pulse 40,000 Amps @ 8/50 μs

Over-Current Protection:
Hydraulic electromagnetic breaker

Wiring System:
6 gauge ArNi® VTX-Ag™ buss system
Ratings: 600 V 105° C

Noise Suppression:
Input to Output (100 kHz – 30 MHz): > 50 dB reduction
Zone to Zone (100 kHz – 30 MHz): > 40 dB reduction


Connectors & Sockets:
Inlet: Proprietary 30A Amphenol
Twist-lock outlet: Proprietary Amphenol
US version: 2 NEMA 5-20R
AS version: 2 NEMA 5-20R
EU version: 2 CEE7/3

KPIP v2 Processing: 4-days

Isolation Zones:
3 zones

Vibration Control:
Vibration dampening panels (internal)
AC outlet dampening gaskets
Shunyata Isolation SSF-38 Footer

Construction:
All aluminum chassis
Anodized, brushed aluminum faceplate

Dimensions:
Width: 17 inches (43.2 cm)
Depth: 10 inches (25.4 cm)
Height: 4.4 inches (11.2 cm)
Weight: 17.5 lbs (7.95 kg)
