This driver works higher into the midrange frequencies and benefits from better detail and dispersion due to the incorporation of a phase plug.
Two of these drive units are used with our ribbon tweeter placed centrally in our K constructed cabinet. A high-quality crossover was specially designed for the K3 to seamlessly mate with the ribbon tweeter. The crossover uses high quality components and is split for bi-wiring.
As far as sound quality goes the K3 has a wonderfully electrostatic type of midrange which is very clear and detailed, with a dynamic bass response.
The K3 is designed for our customers who want a compact speaker that can deliver a powerful sound with ease, such as full orchestral music or loud rock.
*Premium finishes to order at extra cost - Call store for purchase and more info*
SPECIFICATIONS
-
Nominal Impedance: 4 ohms
-
Recommended Amplifiers: 10–250W
-
Frequency Response: 25Hz–30kHz
-
Sensitivity: 89 dB linear for 1 watt at 1 metre
-
Bass/Midrange Drivers: 2 × ProAc 165mm (6.5”) special bass/midrange drive units with Kevlar cones and phase plugs.
-
Tweeter: ProAc ribbon with diaphragm as light as a human hair, alnico magnet and rear chamber damping.
-
Crossover: Finest components on a dedicated dual-layer circuit board. ProAc multistrand oxygen-free copper cable throughout. Split for optional bi-wiring or bi-amplification.
-
Height (Cabinet): 1073mm (42¼”)
-
Width (Cabinet): 210mm (8.5”)
-
Depth (Cabinet): 340mm (13.5”)
-
Weight: 42kg (92.6lbs) per cabinet
-
-
Grille: Acoustically transparent crimplene. Magnetic grilles available with certain finishes.
-
Standard Finishes: Black Ash, Mahogany, Cherry, Natural Oak, Silk White and Walnut.
-
Premium Finishes: Liquidambar, Rosewood and Ebony. Premium finishes available to order at extra cost.
