PH-1 Phono Preamp

Gold Note PH-1 is a shielded MM & MC phono preamplifier featuring an isolated power supply and able to enhance great energy with a
large variety of phono cartridges.

The silent background stage let the unit play low MC cartridges easily down to 0.15mV. PH-1 features a
Gold Note proprietary four double stabilized mono amp stage design to optimize audio performance. The design developed for PH-1 allows
quick matching with any kind of MM and MC cartridge and a wide option of set-ups with easy access impedance setting even below 10ohm
internal impedance without the need of an external step-up transformer. PH-1 enables superior audio purity with any audio system
featuring an optional external super Power Supply (PSU).

Main Details
FREQUENCY RESPONSE 20Hz – 20KHz @ +/- 3dB
THD (Total Harmonic Distortion) <0.05% THD @ 20Hz-20KHz
RATIO SIGNAL TO NOISE -88dB
Audio Inputs
ANALOGUE INPUTS: One stereo RCA
INPUT SENSITIVITY – From 0.15mV MC – up to 6.0mV MM
INPUT IMPEDANCE fixed 470Ω MC variable ▪ 47kΩ MM
GAIN 70dB MC > 48dB MM, > 65dB MC
Audio Outputs
RCA Line output level: 2V RCA fixed
