The NAD CI 980 Multi-Channel Amplifier is designed to deliver reliable, consistent power for custom installation and distributed audio systems. With eight channels of amplification in a single rack-mount chassis, it provides a straightforward solution for driving ultiple zones from a central location. Engineered for stability and long-term operation, the CI 980 focuses on dependable performance and simple system integration. Its balanced design and installer-friendly layout make it well suited for whole-home audio, multi-room music systems, and light commercial installations where reliability and ease of deployment are key priorities.
KEY FEATURES
- 8 channels of FDP-rated amplification at 50 watts per channel
- Designed for multi-zone residential and light commercial installations
- Rack-mount chassis for centralised systems layouts
- Stable performance for continuous operation
- Line-level inputs for system compatibility
- Independent channels for flexible zone assignment
- Designed for long-term reliability in CI environments
- Seamless integration with leading AV control systems
Specifications:
- Power Output:
- 50W × 8 channels into 8 Ω (all channels driven)
- 60W × 8 channels into 4 Ω
- 120W × 4 channels into 8 Ω (bridged mode)
- Total Harmonic Distortion (THD): <0.03% (ref. 20Hz - 20kHz)
- Clipping Power: >155W (ref. 1kHz, 8 Ω, 0.1% THD)
- Frequency Response: 20Hz - 20kHz (± 1dB)
- Signal-to-Noise Ratio (A-weighted): >80dB (ref. 1W/8 Ω); >100dB (ref. 50W)
- Damping Factor: >150 (ref. 8 Ω, 50Hz and 1kHz)
- Inputs: 4 stereo RCA inputs with loop-through, plus global bus inputs
- Outputs: Easy-connect Phoenix style speaker blocks
- Power Consumption: 600W rated power, <26W at idle, and <0.5W in standby
- Dimensions & Weight: 19" x 3.5" x 12.75" (2U rack height); 12.6 lbs (5.72 kg)
