Ortofon

MC Quintet Red

Technical data

Regular price $399.00
- +

Technical data

  • Output voltage at 1 kHz 5 cm/sec 0.5 mV
  • Channel balance< 1.5 dB
  • Channel separation at 1 kHz> 21 dB
  • Channel separation at 15 kHz> 14 dB
  • Frequency range at -3 dB 20 - 25.000Hz
  • Frequency response 20-20.000 Hz+/-2.5 dB
  • Tracking ability at 315 Hz at recommended tracking force *)65 μm
  • Compliance, dynamic, lateral 15 μm/mN
  • Stylus type: Elliptical
  • Stylus tip radius r/R 8/18 μm
  • Tracking force range 2.1-2.5 g (21-25 mN)
  • Tracking force recommended 2.3 g (23 mN)
  • Tracking angle 20º
  • Internal impedance, DC resistance: 7 Ohm
  • Recommended load impedance>20 Ohm
  • Cartridge body material: ABS/Aluminium
  • Coil wire material: Copper
  • Cartridge colour: Red
  • Cartridge weight 9g
