Ortofon

MC Quintet Mono

  • Output voltage at 1 kHz 5 cm/sec: 0.3 mV
  • Frequency range at -3 dB: 20-25.000 Hz
  • Frequency response: 20 Hz - 20 kHz +/-2.0 dB
  • Tracking ability at 315 Hz at recommended tracking force: 70 μm
  • Compliance (dynamic, lateral): 15 μm/mN
  • Stylus type: Nude Elliptical
  • Stylus tip radius: r/R 8/18 μm
  • Tracking force range: 2.1-2.5 g (21-25 mN)
  • Tracking force recommended: 2.3 g (23 mN)
  • Tracking angle 20º
  • Internal impedance, DC resistance: 5 Ohm
  • Recommended load impedance: 20 Ohm
  • Cartridge body material: ABS/Aluminium
  • Coil wire material: Pure 4-nines copper
  • Cartridge colour: White
  • Cartridge weight: 9 g
Regular price $549.00
- +
