Description

Lina DAC X is designed to reveal the full impact of your music. It presents all aspects of a recording - from individual sounds to the subtle timing and spatial cues that bring us a sense of space and depth - with remarkable clarity, for an exhilarating and immersive sonic experience.

Lina DAC X reflects dCS's vision to deliver incredible sound and a convenient, intuitive playback experience. It streams hi-res audio from all major platforms and plays files from various digital sources including computers, storage drives and CD Transports.

It is the latest addition to a product series that has won numerous awards worldwide for its sonic capabilities. It delivers all the qualities listeners have come to expect from dCS – including outstanding resolution and fidelity, meticulous craftsmanship, and a wide range of inputs and streaming options – to ensure an outstanding performance and seamless integration with existing audio equipment.
Specifications

Product Dimensions

122mm / 4.80" (H) x 444mm / 17.48" (W) x 356mm / 14.02" (D). Allow extra depth for cable connectors.

Weight

14KG / 30.86lbs

Analogue Outputs

  • 1 stereo balanced pair on 2x 3-pin male XLR
    connectors (pin 2 = hot, pin 3 = cold). These outputs are electronically
    balanced and floating, the signal balance ratio at 1 kHz is better than
    40dB. Output impedance is 3Ω, maximum load is 600Ω (a 10kΩ - 100kΩ load
    is recommended)
  • 1 stereo unbalanced pair on 2x RCA Phono
    connectors. Output impedance is 52Ω, maximum load is 600Ω (a 10kΩ -
    100kΩ load is recommended)
  • Output levels are 0.2V, 0.6V, 2V, or 6V rms for a full-scale input, set in the menu.

L-R Crosstalk

Better than –115dB0, 20Hz-20kHz

Streaming

Supports the following platforms and services:

  • UPnP
  • Internet Radio
  • Qobuz
  • Spotify
  • Deezer
  • Tidal
  • Roon Ready
  • QQ Music

Upsampling

Multi-stage DXD oversampling with switchable DSD
Upsampling (1-bit 2.822 or 3.07MS/s) and DSDx2 Upsampling (1-bit 5.644
or 6.14MS/s).

Digital Inputs

  • 2 x AES/EBU on 3 pin XLR 44.1-192kS/s
  • Used as a Dual AES pair (1+2), supports sample rates up to 384kS/s
  • 1 x S/PDIF BNC Coax 44.1-192kS/s
  • 1 x S/PDIF on RCA 44.1-192kS/s
  • 1 x Toslink 44.1-96kS/s
  • 1 x USB Type B 44.1-384kS/s PCM and DSD, DSDx2 in Asynchronous Mode
  • 1 x USB Type A connector for mass storage devices (navigated using Mosaic)

Frequency Response
(set to filter 1)

  • Fs = 44.1 or 48kS/s +/-0.1dB, 10Hz-20kHz
  • Fs = 88.2 or 96kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >38kHz
  • Fs = 176.4 or 192kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >67kHz
  • Fs = 352.8 or 384kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >100kHz
  • DSD64 +/-0.1dB, 10Hz-20kHz -3dB @ >90kHz
  • DSD128 +/-0.1dB, 10Hz-20kHz -3dB @ >100kHz

Residual Noise
(6v output setting)

  • 16-bit data: Better than –96dB0, 20Hz-20kHz unweighted
  • 24-bit data: Better than –113dB0, 20Hz-20kHz unweighted

Sample frequencies and formats

Supports the following audio formats and sample rates:

  • 44.1-384kS/s up to 24 bits
  • DSD/64, DSD/128
  • Native DSD + DoP (input dependent)
  • FLAC, WAV, AIFF, MQA

Power Requirements

  • 90-127V / 220-240V, 50/60Hz
  • Power consumption 30W
