Mark Twain famously said, “It’s not the size of the dog in the fight, it’s the size of fight in the dog.” Totem concurs, and nothing exemplifies the quote more than the marvelously compact and enormously powerful KIN SUB 8.
Its wonderfully contradictory characteristics are enabled by innovative technology and ingenious engineering. The 8” Reinforced Fiberglass Woofer and oversized, vented magnetic structure initiate profound bass impact. Powered to thunderous perfection by our dynamic 200W digital amplifier, KIN Sub 8 strikes the perfect balance of musicality and brute force.
Easy to integrate into any lifestyle and perfectly appropriate for any application, KIN Sub 8 will accentuate the bass excitement of every music, movie, or gaming experience.
Design Highlights
- Extremely compact for easy home integration
- Ultra low-profile anti resonance feet
- Simple connection options
- Exquisite Black and White Satin finish with matching magnetic grill
Technical Features
- 8” Reinforced Fiberglass woofer with aluminum voice coil
- 200 watt Class D high efficiency amplifier
- Variable volume / phase / frequency adjustments for pinpoint accuracy
- Slot Ported for Extended low frequency capability
Specifications
| Design: |
Powered Subwoofer |
| Enclosure: |
Slot ported |
| Amplifier: |
Class D 200 watts |
| Woofer: |
8” Reinforced Fiberglass cone with Butyl rubber surround. |
| Voice coil: |
Enamel resin coated copper wire wound on a vented aluminum former |
| Frequency response: |
29 Hz – 200 Hz |
| Crossover: |
Variable from 40Hz to 120Hz, 24dB/Octave |
| Phase: |
Variable from 0 to 180 degrees |
| Volume: |
Variable |
| Inputs: |
Stereo RCA/LFE |
| Power modes: |
Auto/On |
| Dimensions (HxWxD) : |
11 7/32” x 10 7/16” x 11 1/2” / 285mm x 265mm x D 292mm |
| Weight: |
16.4 lb / 7.5 kg |
