Yamaha
GT-5000
- Balanced output achieves full balanced signal process from cartridge to speaker
- GT Series design
- Straight, short arm for transparency and openness in sound
- Custom belt-drive mechanism (AC synchronous motor)
- 5 kg aluminium platter
Turntable | Drive Method | Belt drive |
---|---|---|
Motor | AC synhronous motor | |
Motor Drive | Crystal sine wave | |
Rotation Speed | 33-1/3 rpm, 45 rpm | |
Rotation Speed Variation | ±0.1% | |
Rotation Speed Adjustment | Built-in crystal osc. Adjustment Step: 0.1%, Adjustment Range: ±1.5% | |
Wow And Flutter | less than 0.04% | |
Platter | [Outer] Machined aluminium (Diameter 35 cm), [Inner] Brass (Diameter 14.3 cm), | |
Tonearm | Tonearm | Static balance straight tonearm |
Effective Arm Length | 223 mm | |
Overhang | -17 mm | |
Acceptable Cartridge Weight | 13.5-36 g (including headshell) / (25-36 g need sub weight) | |
Attached Cartridge | Head-shell Weight | 14 g (including screws, nuts and wires) |
Audio Specifications | Output Terminal | Analogue Audio: 2 (XLR balance x 1, RCA unbalance x 1), Strobe: 1 (3.5 mm mini jack) |
General | Power Consumption | 15 W |
Dimension (W×H×D) | 546 x 221 x 411 mm; 21-1/2"x 8-3/4"x 16-1/8" | |
Weight | 26.5 kg; 58.4 lbs. |
