The Gold Note HP-10 Deluxe is a high-end Dual-Mono Class-A balanced headphone amplifier designed for demanding headphone systems. Its signal path is fully analog and uses discrete components, with extensive analog controls that let you tailor the presentation to different headphones and listening preferences.
The Deluxe adds a premium AKM AK4493 DAC, USB-C digital input and Bluetooth 5.1 HD aptX, allowing it to operate as a standalone headphone system with a computer, smartphone or tablet. It also provides both balanced and unbalanced analog inputs and four different headphone connection formats.
Beyond headphone amplification, the HP-10 Deluxe can function as a line preamplifier, with RCA and XLR outputs. Its Studio features include adjustable Crossfeed, Harman Curve and Superflat EQ, damping-factor adjustment, variable gain, channel balance and 0°/180° phase selection. A touchscreen, rotary control and included remote provide control, while a 12V trigger and bypass function make it suitable for integration into larger hi-fi systems.
SPECIFICATIONS
-
Type: Dual-Mono Class-A Headphone Amplifier
-
DAC: AKM AK4493
-
Digital Inputs: USB-C, Bluetooth 5.1 HD aptX
-
USB-C: PCM up to 32-bit/768 kHz; DSD512
-
Analog Inputs: 1 × RCA, 1 × XLR
-
Headphone Outputs: 3.5 mm, 6.3 mm, 4.4 mm balanced, 4-pin XLR balanced
-
Line Outputs: 1 × RCA, 1 × XLR
-
Maximum Headphone Output: 10 W
-
Frequency Response: 20 Hz–20 kHz ±0.3 dB
-
THD+N: 0.015% @ 1 kHz
-
S/N Ratio: 110 dB
-
Crossfeed: Adjustable — full spectrum, bass, mids or highs
-
Analog EQ: Harman Curve, Superflat
-
Damping Factor: High / Low
-
Phase: 0° / 180°
-
Gain: Variable
-
Channel Balance: Adjustable
-
Stereo/Mono: Selectable
-
Preamp Function: Yes
-
Trigger: 12V In/Out
-
Power Supply: 100–240 V, 50/60 Hz
-
Power Consumption: 25 W max
-
Dimensions: 200 × 80 × 260 mm
-
Weight: 3.5 kg net / 4.5 kg boxed
-
Optional Upgrade: PSU-10 EVO external power supply
