Sale Sold out

Shunyata Research

Everest-X

Everest-X

$24,000.00 CAD
$24,000.00 CAD
Description

The Everest-X is the most advanced power distributor in our company’s 25-year history. As the successor to the award-winning Everest 8000, the Everest-X represents a new summit in the pursuit of absolute fidelity, offering a previously unattainable level of resolution, timing, and emotional engagement.

Built upon decades of research and scientific refinement, the Everest-X redefines what is possible in power delivery. Whether anchoring a world-class mastering studio or unlocking new dimensions of musical immersion in a home system, Everest-X delivers unseen vistas of sonic truth.
Specifications

Maximum Voltage:

90-125 VAC r.m.s. unregulated (US)

220-240 VAC r.m.s. unregulated (UK, EU, AS, AU)

Input Current Ratings:

Maximum Continuous Current: 30A (US, AS)

Maximum Continuous Current: 16A (UK, EU, AU)

Output Current Ratings:

Max Current/Outlet: 20A (US, AS)

Max Current/Socket: 16A (EU, UK, AU)

Transient Suppression:

Maximum Transient Protection: 40,000 A @ 8/50 μs

Over-Current Protection:

Hydraulic Electromagnetic Breaker

Wiring System:

8 gauge ArNi® VTX™ Buss System

10 gauge ArNi® VTX™ Wiring

Ratings: 600 V 105° C

Noise Suppression:

Input to Output (100 kHz – 30 MHz): > 50 dB reduction

Zone to Zone (100 kHz – 30 MHz): > 60 dB reduction

Outlets & Connectors:

Zones of Isolation: 6 Zones

Inlet: IEC C19R

US Outlets: 8 NEMA5-20R (CopperCONN™ Platinum)

KPIP v2 Processing: 8-days

Vibration Control:

Vibration dampening panels (internal)

AC outlet dampening gaskets

Shunyata Isolation SSF-50 Footer

Construction:

Aluminum and steel chassis

Anodized, aluminum faceplate

Ground Terminals: OFE pure copper

GPNR:

Length: 127 mm

Diameter: 38 mm

Dimensions:

Width: 8.0 inches (20.32 cm)

Depth: 14.75 inches (37.47 cm) with cable cradle

Depth: 13.5 inches (34.29 cm) without cable cradle

Height: 20.75 inches (52.71 cm)

Weight: 34 lbs (16 kg)

 View full details
Everest-X

Shunyata Research

Everest-X
$24,000.00 CAD
$24,000.00 CAD
