Paradigm XR13 13" Subwoofer

The all-new XR subwoofers are a master class in design and engineering refinement that challenges what is possible from a compact, sealed subwoofer design. Our goal was to push the boundaries of performance while never losing sight of aesthetics by wrapping everything up into a suitable size that won't ever feel out of place.

*Premium finishes to order at extra cost*

SPECIFICATIONS

• Design: 13” (330 mm) Ultra-high Excursion Driver with Trilinear Suspension System and Active Ridge Technology (ART™), sealed enclosure with Cascade-Fusion™ Bracing and ADVANCED Shock-Mount™, built-in Class-D amplifier, App-controlled via smartphone and Anthem Room Correction (ARC®) Included

• Amplifier features: Auto-On / Off, Trigger On / Off

• Room correction: ARC Genesis (microphone included)

• Frequency response on-axis: ±3dB from 17 Hz to 140 Hz

• Low frequency driver: 13” (330 mm) Ultra-High-Excursion CARBON-X Unibody Bass Driver, with Trilinear Suspension System and Active Ridge Technology (ART™), 2” high-temperature voice coil

• Effective piston area (SD): 93.7 sq in / 0.06 sq m

• Effective displacement: 366.1 cu in / 6 L

• Low frequency response: 12 Hz (DIN)

• Amplifier power: Power measurements underway to ensure compliance with new FTC regulations

• Unbalanced inputs: Stereo or Mono (dual RCA jacks) / LFE RCA jack

• Balanced inputs: One Balanced XLR (LFE)

• Speaker/high-level inputs: Left and right speaker level inputs

• Input grounding: Grounded

• Polarity: 0 or 180 degrees

• Phase: Variable 0°–180°

• Dimensions H×W×D: 18.8” × 17.3” × 19.4” (47.8 cm × 43.8 cm × 49.3 cm)

• Weight: 103.8 lb / 47.1 kg

• Finishes: Gloss: Piano Black & Midnight Cherry; Satin: Walnut & Black Walnut
