TechDAS

Air Force V Premium

TechDAS push back the boundaries of design again with the Airforce V Premium, successfully preserving all “Air Force” technologies in the most affordable model of the line.

Regular price $17,000.00
- +

TechDAS push back the boundaries of design again with the Airforce V Premium, successfully preserving all “Air Force” technologies in the most affordable model of the line.

The Air Force turntables feature unique and refined “air” technologies which includes our air bearing that allows the platter to flow on a very thin layer of air and mechanically isolates the rotating platter and a record from any vibration, as well as vacuum hold down of an LP onto the platter. With these technologies, the Air Force turntables have distinguished themselves from conventional turntables in terms of sound and performance.

The Air Force V Premium has been developed to deliver another dimension in analog sound, and at the same time be accessible to more analog enthusiasts. The chassis is as compact in size as the Air Force III Premium, and by elaborately reducing motor vibration TechDAS have achieved a successful integration of the motor in the plinth. The result is an even more compact turntable without a separate motor unit that can be fitted with up to four tonearms.

The 2-phase 4-pole AC synchronous motor offers almost the same level of performance as the upper models and is integrated into the main unit with an anti-vibration mechanism optimally designed. The polished drive belt of polyurethane rubber helps achieve a high signal to noise ratio. Furthermore, the chassis with the built-in motor sits on four feet which are based on the air damping approach TechDAS have used successfully in the Air Force III.

MAIN UNIT INCLUDING BUILT IN MOTOR
Chassis Precision machined aluminum alloy (A5052)
Silver anodized satin finish 19.0 kg
Platter Sub platter system, Precision machined aluminum alloy (A5056)
Total 7.0k Outer-main platter: black anodized, 4.0 kg
Inner-sub platter: silver anodized, 3.0kg
Total moment of inertia 734 kg・cm2
Drive system Belt-drive with polished polyurethane rubber belt
Motor 2-phase 4-pole AC synchronous motor built in the chassis
Motor Power Supply Digital rotational control system driven by power amplifier
Rotational speed 33.3 rpm/ 45 rpm
Wow & Flutter below 0.03%
Dimensions 312 (W) x 168 (H) x 368 (D) mm
Total weight 26.0 kg
Minimum dimensions for setting up 413 (W) x 418 (D) mm
POWER SUPPLY, PUMP UNIT & AIR CONDENSER UNIT
Power consumption 50W
Dimensions Dimension: 350 (W) x 160 (H) x 270 (D) mm
Weight 9 kg
Minimum dimensions for setting up 350 (W) x 330 (D) mm
INCLUDED ACCESSORIES
Tonearm Base x 1 (Extra cost may be incurred dependant on the chosen tonearm)
Platter Cover x 1
OPTIONAL ITEMS & ACCESSORIES
Extra Tonearm Base
