761

The MOON 761 has one job to perform, and it performs it with authority. This power amplifier effortlessly delivers delicate audio signals from a preamplifier to loudspeakers with absolute transparency and finesse.

Design features

• MDCA – MOON Distortion-Cancelling Amplifier
• No Global Feedback Design
• MOON Transistors
• Dual Mono Configuration
  Monaural Mode Toggle Switch
• MOONLink
• Multicolour LED Indicator

Specifications



• Output Power (Stereo 8 Ω): 200 W
• Output Power (Stereo 4 Ω): 400 W
• Output Power (Mono 8 Ω): 600 W
• Input Sensitivity: 1.1 V
• Input Impedance: 47 kΩ
• Gain: 31 dB
• Frequency Response: 2 Hz – 100 kHz (+0 dB / –3 dB)
• Crosstalk: –116 dB
• Signal-to-Noise Ratio: 117 dB
• Total Harmonic Distortion + Noise (@ 1 W): 0.002%
• Total Harmonic Distortion + Noise (@ 200 W): 0.001%
