Ortofon

MC Quintet Black S

MC Quintet Black S

$1,484.00 CAD
$1,484.00 CAD
Description

The Quintet Black is graced with a Nude Shibata diamond, considered one of the best stylus profiles available, mounted on a high-performance Boron cantilever.

The Shibata’s slim, highly polished profile allows an exceedingly wide contact area to the walls of the groove and ensures detailed and pure reproduction thoughout the spectrum, including even the most high frequency groove information.
Specifications
  • Output voltage: 1000 Hz, 5cm/sec. - 0.3 mV
  • Channel balance: 1 kHz - < 1.0 dB
  • Channel separation: 1 kHz - > 23 dB
  • Channel separation: 15 kHz - > 15 dB
  • Frequency range: - 3dB - 20 - 25.000 Hz
  • Frequency response 20-20.000 Hz - +/- 1.5 dB
  • Tracking ability: 315Hz at recommended tracking force *) - 80 µm
  • Compliance, dynamic, lateral: 15 µm/mN
  • Stylus type: Nude Shibata on Sapphire cantilever
  • Stylus tip radius: r/R 6/50 µm
  • Tracking force range: 2.1-2.5 g (21-25 mN)
  • Tracking force, recommended: 2.3 g (23 mN)
  • Tracking angle: 20°
  • Internal impedance, DC resistance: 5 Ohm
  • Recommended load impedance: > 20 Ohm
  • Cartridge body material: ABS/Aluminium
  • Coil wire material: Aucurum
  • Cartridge colour: Black
  • Cartridge weight: 9 g
